Powerware 5075 kVA - Manual (Page 154)

A---22 Powerware BPIII Harsh Environment UPS 50--75 kV Installation and Operation
164291261 Rev. F 111503
MAX. WIRE SIZE: NO. 14 AWG
MIN. WIRE SIZE: NO. 18 AWG
WIRES MUST
CONDUIT AND WIRING SUPPLIED BY
CUSTOMER. MAX. DISTANCE BETWEEN
REMOTE MONITOR AND UPS NOT TO
EXCEED 500 FEET.
41.1
(1.62)
25.4
(1.00)
190.5
(7.50)
88.9
(3.50)
215.9
(8.50)
100.1
(3.94)
74.7
(2.94)
171.5
(6.75)
KNOCKOUTS PROVIDED
ON FIVE SURFACES
BE TWISTED
FLUSH MOUNT
SURFACE
(FOR HANGING)
(14---18 gauge)
Dimensions are in millimeters (inches)
MOUNT
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVISION: A
164201261---7
REMOTE MONITOR PANEL
1 of 1
053099
285.7
(11.25)
(7.75)
.75
197.47
(8.50)
216.58
