94 Powerware BPIII Harsh Environment UPS 50--75 kV Installation and Operation
164291261 Rev. F 111503
Meters Printout (Ctrl + M)
This key sequence prints the current readings of the UPS system meters. The
Input area shows the phase-to-phase voltage, frequency, and phase current of the
incoming utility, followed by the kVA, kW, and power factor measurements. The
output area shows the same information for the power being output by the UPS.
The Bypass area shows the phase-to-phase voltage of the bypass source. The
Battery area displays the DC voltage (V) and the DC current (I). Figure 45 shows
a sample Meters printout.
Input Output
Bypass Battery
VAB
480
VBC VCA
KW
69
KVA
73
IA IB IC
FREQ
60.0
PF
0.95
V
540
I
0
88
480 480
88 88
VAB
480
VBC VCA
480 480
IA IB IC
222 222 222
IN
0
VAB
208
VBC VCA
208 208
FREQ
60.0
KVA
80
KW
64
PF
0.80
Uninterruptible Power System
UPS System Normal
Alarm: None
Notice: None
03 JAN 1994 14:22:49
+
Figure 45. System Meters
System Information Printout (Ctrl + A)
This key sequence prints a listing of all available serial data. This printout contains
the information shown on the Event History Log and Meters screens of the UPS
(both Figures 44 and 45).
