VTrak M-Class Product Manual
58
Figure 2. VTrak M300f/i/p and M200f/i/p front panel LED display
When boot-up is finished and the VTrak is functioning normally:
• Controller LED blinks green once per second for five seconds, goes dark for
ten seconds, then blinks green once per second for five seconds again.
• Power, FRU, and Logical Drive LEDs display green continuously.
• Fibre Channel/iSCSI/SCSI LEDs flash green if there is activity on that
channel.
See the table below.
Power
FC/iSCSI/SCSI-2 Activity
FRU Status
Logical Drive Status
FC/iSCSI/SCSI-1 Activity
Controller Heartbeat
