VTrak M-Class Product Manual
12
Mount VTrak M500f/i/p in a Rack
Figure 1. Rackmounted VTrak M500f/i/p
The VTrak M500f/i/p installs directly to the rack with or without using the supplied
mounting rails.
Figure 2. Mounting rail installation
PROMISE VTrak M500f
Vertical Rack Post
Direct attach to post
Mounting Rail
(included)
VTrak M500f/i/p
VTrak attaching screw
Back side of post
Rack front post
Rail attaching screw
(not included)
Rail adjustment screw
Mounting
Rail
Rail attaching screw
(not included)
Back side
of post
Rack rear post
VTrak subsystem
