Chapter 2: Installation
25
Set Up Serial Cable Connections
The RS-232 Serial connection enables the Command Line Interface (CLI) and
Command Line Utility (CLU) on your PC to monitor and control VTrak.
Figure 13. Serial connectors for VTrak M500f (left) and M300i (right)
Mgmt IOIOI
Controller
1 2 FC 1 FC 2
Mgmt
IOIOI
Controller
1 2
FC 1 FC 2
iSCSI 1 iSCSI 2
IOIOI
Controller
Mgmt
iSCSI 1 iSCSI 2
IOIOI
Controller Mgmt
DB-9 Serial
Connector DB-9 Serial
Connector
