Example Setups
5•2
Recording Tone 1 & 2 to Separate Stereo Tracks ( POD X3 Live
& POD X3 Pro only )
1. Connect the 1/4-inch left/right outputs to your recorder as the source for the first track, and the XLR left/
right outputs as the source for the second track.
2. Set the second OUTPUTS page (Studio/Direct Mixer):
Mode: Studio/Direct •
Tone 1: Off •
Tone 2: On (the XLRs will output Tone 2 only) •
Tone 2 Pan: Center •
3. Set the first OUTPUTS page (1/4-inch jacks Outputs):
Mode: Studio/Direct Tone 1 •
Feed One Guitar Amp
1. Connect 1/4-inch output(s) to your amp or speaker system.
2. Set the first OUTPUTS page (1/4-inch Outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stack PwrAmp. •
Lows, Focus, Highs: as desired •
Tone 1: On •
Tone 1 Pan: Center •
Tone 2: On •
Tone 2 Pan: Center •
3. Check your Master Volume.
Select the loudest preset/settings you intend to use. •
Play your instrument and turn Master Volume as high as you can without clipping the amp/speakers •
you’re feeding.
Feed Two Guitar Amps, One for Tone 1 and One for Tone 2
1. Connect the left 1/4-inch output to one amp, and the right 1/4-inch output to the other.
2. Set the first OUTPUTS page (1/4-inch Outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stck PwrAmp. •
Lows, Focus, Highs: as desired •
Tone 1: On •
Tone 1 Pan: Full Left •
Tone 2: On •
Tone 2 Pan: Full Right •
3. Check your Master Volume.
Select the loudest preset/settings you intend to use. •
Play your instrument and turn Master Volume as high as you can without clipping the amp/speakers •
you’re feeding.
