Line 6 POD X3 Family - Manual (Page 43)

Reference: Tweaking Tones
3•11
Effects Loop ( POD X3 Live & POD X3 Pro only )
EFFECT LOOP 1
TYPE BYP VOL
75% 75% 75%
TYPE
-58dB 100%
SEND MIX RETURN CONFIG
+24dB
POST
This lets you tweak the settings related to the Effects Loop. Note that the Loop can only be on for one Tone
at a time, and turning the Loop on for one Tone automatically forces it off for the other.
Send – adjusts the gain of the send output from -80 to 0 dB.
Return – adjusts the gain of the return inputs from 0 to +24 dB.
Mix – 0-100%: set this to 100% for parallel-style operation.
Config – allows you to place the Effect Loop in two different locations in the POD X3 Live and POD X3
Pro’s signal chain:
Pre –
• after the Stomp block, before the Mod and Delay blocks.
Post –
• before the Mod, Delay and Reverb blocks.
If nothing is connected to the loop, POD X3 Live and POD X3 Pro are smart enough to disable the loop so
you still get sound.
