7

Event memory - entries

You can browse in the event memory by the use of the '

↑↓

'-buttons. The first three lines of the LC-

display show the event text as well as the free programmable text information on the event, and provide
additional information on events on the control panel. By pressing the 'Info'-button, additional texts
(e.g., the reason for a given fault) appear, as well as the date and time of the occurrence or of the termi-
nation of the event.

Event

Event text

Text 2nd line

Text 3rd line

Additional text

(info-button)

Fire detector zones/elements

Activation

ALARM 0001/001

zone text 1

zo. text 2 / element text

Activation termination

ALARM.T 0001/001

zone text 1

zo. text 2 / element text

Disablement

DISABLEM. 0001/001

zone text 1

zo. text 2 / element text

Enablement

ENABLEMENT 0001/001

zone text 1

zo. text 2 / element text

Fault

FAULT 0001/001

zone text 1

zo. text 2 / element text

fault cause

Fault termination

FAULT.T 0001/001

zone text 1

zo. text 2 / element text

fault cause

Pre-alarm

PRE-AL 0001/001

zone text 1

zo. text 2 / element text

Pre-alarm termination

PRE-AL.T 0001/001

zone text 1

zo. text 2 / element text

Test activation

TEST-AL 0001/001

zone text 1

zo. text 2 / element text

Test activation termination

TEST-AL.T 0001/001

zone text 1

zo. text 2 / element text

Test condition off

TEST COND.T 0001/001

zone text 1

zo. text 2 / element text

Test condition on

TEST COND 0001/001

zone text 1

zo. text 2 / element text

Technical detector zones/elements

Activation

TECH.MSG 0001/001

zone text 1

zo. text 2 / element text

Activation termination

TECH.MSG.T 0001/001

zone text 1

zo. text 2 / element text

Disablement

TECH.DIS 0001/001

zone text 1

zo. text 2 / element text

Enablement

TECH.ENA 0001/001

zone text 1

zo. text 2 / element text

Fault

TECH.FLT 0001/001

zone text 1

zo. text 2 / element text

fault cause

Fault termination

TECH.FLT.T 0001/001

zone text 1

zo. text 2 / element text

fault cause

Test activation

TECH.T-AL 0001/001

zone text 1

zo. text 2 / element text

Test activation termination

TECH.T-AL.T 0001/001

zone text 1

zo. text 2 / element text

Test condition off

TECH.TEST.T 0001/001

zone text 1

zo. text 2 / element text

Test condition on

TECH.TEST 0001/001

zone text 1

zo. text 2 / element text

Fault detector zones/elements

Activation

FLT-ALARM 0001/001

zone text 1

zo. text 2 / element text

Activation termination

FLT-ALARM.T 0001/001

zone text 1

zo. text 2 / element text

Disablement

FLT.DIS 0001/001

zone text 1

zo. text 2 / element text

Enablement

FLT.ENA 0001/001

zone text 1

zo. text 2 / element text

Fault

FLT.FLT 0001/001

zone text 1

zo. text 2 / element text

fault cause

Fault termination

FLT.FLT.T 0001/001

zone text 1

zo. text 2 / element text

fault cause

Test activation

FLT.T-AL 0001/001

zone text 1

zo. text 2 / element text

Test activation termination

FLT.T-AL.T 0001/001

zone text 1

zo. text 2 / element text

HB216AE.SAM / 0130 / AN9161202

ZN5002/73/68

68

Chapter 7 • Event memory - entries
