3 Displaying and operating elements
The functions and effects of the displaying and operating elements of the fire detection control panel
Series BC216 and the optional protocol printer are described in this chapter. The operation of the con-
trol panel itself is described starting page 29 in Chapter 4: "Basic operation of the fire detection control
panels Series BC216" and starting page 49 in Chapter 5: "Operating conditions of fire detection control
panels Series BC216".
For reasons of simplicity the BCnet sectional control panels of the fire detection control panel
BCnet216 equipped with an display and operating unit are named "operable BCnet sectional control
panels" in the following paragraphs of this chapter.
Figure 4: Displaying and operating elements of the fire detection control panel Series BC216
Actuation activ ated
Tec hnic al me ssage
Dis able ment
Test condition
Energy fault
System fault
Authorization
Act i v a t ed
Fault/Disabled
Al a rm d e l ay
Confirmation
Call fire brigade
Act iv at ed
Fault/Disabled
TRANSM . DEVICE 1
P O W E R
F AULT A L A R M
BC216-1
El e m e n t
I n fo
Al a rm d e l ay
Exp lore
On / o f f
ALARM . D EVIC E 1
e s c 0
1 2 3
4 5 6
7 8 9
↓
↑
← →
Silence buzzer Pan e l r es e t
0
?
↵
INFO-field
INFO-button
MENU-buttons
ELEMENT-button
NUMERIC keys
RESET-buttons
LED-summary displays
optional
LED-display field
ALARMING DEVICE 1 - field
TRANSMITTING DEVICE 1 - field
