4.7.2 Displaying activated actuations - menu point [Activated actuations]
Scroll through all activated actuations by using the '
↑↓
'-buttons (details see from page 55 in Chapter
5.3: "Activation condition of actuations"). Note that activations of transmitting devices and of alarming
devices are displayed as activated actuations as well.
1.TR-DEV.ACT 01
>
1.ALARM 0003/029 3.ACTU.ACT 0001
1.ALARM 0003/029
Figure 8: Examples for the display of an actuation activation.
Left figure: Transmitting device Nr. 1 is activated as the first actuation.
Right figure: Actuation Nr. 1 is activated as the third actuation. Has no element text been pro-
grammed, the second line of the actuation text (if available) is displayed.
4.7.3 Displaying technical messages - menu point [Technical messages]
Scroll through all current technical messages by using the '
↑↓
'-buttons (details see from page 56 in
Chapter 5.4: "Message condition for technical messages").
1.TECH.MSG 0005/011
Figure 9: Example for the display of a technical message from detector zone 5, detector Nr. 11. Has no element
text been programmed, the second line of the zone text (if available) is displayed.
In this case, the '
↵
'-button has a special function: The detector zone whose technical message is cur-
rently displayed is disabled by using this button.
4.7.4 Displaying fault messages - menu point [Faults]
Scroll through all current faults by using the '
↑↓
'-buttons (details see from page 58 in Chapter 5.5:
"Fault-message condition").
1.ACTU.FLT 0003/018
2.ENERGY FAULT
stand-by battery
Figure 10: Example for the display of faults
Left figure: Display of a fault of actuation Nr. 3, element Nr. 18. Has no element text been pro-
grammed, the second line of the actuation text (if available) is displayed.
Right figure: Energy fault, fault of the stand-by battery. In addition to the fault cause, the name and
number of the concerning BCnet sectional control panel (=GSSnet member number) are displayed if
the fault of a part of a BCnet sectional control panel of the network fire detection control panel
BCnet216 is reported.
Faults that are detected by the control panel itself (e.g., a fault of the function of a part of the control
panel) as well as faults that are transmitted to the control panel by connected fault detectors are dis-
played in this menu point.
In this case, the '
↵
'-button has a special function: The detector zone whose fault message is currently
displayed is disabled by using this button.
4.7.5 Displaying disablements - menu point [Disablements]
Scroll through all current disablements by using the '
↑↓
'-buttons (details see from page 61 in Chapter
5.6: "Disablement condition").
