Additional information (e.g., date and time of the test procedure, the number of current test procedures,
hints for operating the menu, hints for authorization) can be displayed by using the 'Info'-button. You
can scroll through all current test procedures by using the '

↑↓

'-buttons.

The following test conditions are displayed on the LC-display of the control panel:

Condition

Displaying (1st line)

Test condition of a detector zone (e.g., Nr. 4) for fire alarm

1.TEST COND 0004

Test condition of an element (e.g., Nr. 29) of a detector zone (e.g., Nr. 4)
for fire alarm

1.TEST COND 0004/029

Test condition of a detector zone (e.g., Nr. 3) for technical messages

1.TECH.TEST 0003

Test condition of an element (e.g., Nr. 5) of a detector zone (e.g., Nr. 3)
for technical messages

1.TECH.TEST 0003/005

Test condition of a detector zone (e.g., Nr. 5) for faults

1.FLT.TEST 0005

Test condition of an element (e.g., Nr. 14) of a detector zone (e.g., Nr. 5)
for faults

1.FLT.TEST 0005/014

Alarm of a detector zone (e.g., Nr. 4) for fire alarm, being put in test
condition

1.TEST-AL 0004

Alarm of an element (e.g., Nr. 29) of a detector zone (e.g., Nr. 4) for fire
alarm, being put in test condition

1.TEST-AL 0004/029

Alarm of a detector zone (e.g., Nr. 3) for technical messages, being put in
test condition

1.TECH.T-AL 0003

Alarm of an element (e.g., Nr. 5) of a detector zone (e.g., Nr. 3) for tech-
nical messages, being put in test condition

1.TECH.T-AL 0003/005

Alarm of a detector zone (e.g., Nr. 5) for fault messages, being put in test
condition

1.FLT.T-AL 0005

Alarm of an element (e.g., Nr. 14) of a detector zone (e.g., Nr. 5) for fault
messages, being put in test condition

1.FLT.T-AL 0005/014

Test activation of a transmitting device (e.g., Nr. 1)

1.TR-DEV.TEST 01

Test activation of an alarming device (e.g., Nr. 1)

1.AL-DEV.TEST 01

Test activation of an actuation (e.g., Nr. 1)

1.ACTU.TEST 0001

Test activation of an element (e.g., Nr. 4) of an actuation (e.g., Nr. 1)

1.ACTU.TEST 0001/004

Table 6:

Messages of test conditions

You terminate a test procedure by disabling the corresponding detector zone. The displays of test con-
ditions remaining in the display memory are renumbered in the order of their occurrence.

HB216AE.SAM / 0130 / AN9161202

ZN5002/73/64

64

Chapter 5 • Operating conditions of fire detection control panels Series BC216

User Manual Series BC216 / Part A
