6.3

Reconditioning and maintenance

Parts of the system that have a fault are not able to perform their functions efficiently or at all. There-
fore have faults repaired as soon as possible by a qualified and authorized company, preferably the one
that performs the periodic maintenance of your system.

Fire detection systems have to be serviced and - if necessary - reconditioned periodically by a qualified
maintainer. Only specialized companies that are demonstrably periodically trained specifically for the
functions of this specific fire detection system by LST or by persons being explicitly authorized by
LST.

A fire detection system that has not been serviced at all or not competently may not be able to
fulfill its purpose to detect a fire reliably and fast. Aside from the resulting gross negligence dan-
ger to human life and to property, a fire insurance may reject the claim for compensation in
such cases!

6.4

Specifications of control panel devices of Series BC216

Mains voltage

230VAC +10/-15%, 50Hz

Power requirement

60VA

Supply current

max. 0.26A

Output-/rated voltage

typ. 28VDC

Peak current

max. 1.8A

Case

steel sheet, 1mm, powder coated

Colour

grey-white, RAL9002

Dimensions w × h × d

420 Ч 520 Ч 120 (mm)

Weight without battery

ca. 6kg

Ambient temperature

-5°C to +50°C

Relative humidity of air

95% (not condensed)

Further detailed specifications are available in Part B of the User Manual of the fire detection control
panel Series BC216.

HB216AE.SAM / 0130 / AN9161202

ZN5002/73/67

User Manual Series BC216 / Part A

Chapter 6 • Ensuring the efficacy of the system by the user

67
