TK-7150
27
PARTS LIST
CN731-756 E23-1081-05 TERMINAL
J700 ✽ E58-0494-05 SUB SOCKET (D)
F100 ✽ F53-0278-05 FUSE
CF201 ✽ L72-1002-05 CERAMIC FILTER
CF202 L72-0372-05 CERAMIC FILTER
CF203 ✽ L72-1002-05 CERAMIC FILTER
CF204 L72-0372-05 CERAMIC FILTER
L2,3 L40-6875-92 SMALL FIXED INDUCTOR (68NH)
L4 ✽ L41-2775-20 SMALL FIXED INDUCTOR
L5 ✽ L41-1875-20 SMALL FIXED INDUCTOR
L6 L34-4520-05 AIR-CORE COIL
L7 L34-4602-05 AIR-CORE COIL
L8 L34-4520-05 AIR-CORE COIL
L9 L34-4518-05 AIR-CORE COIL
L10 L34-4523-05 AIR-CORE COIL
L11-14 L34-4520-05 AIR-CORE COIL
L15 L34-4523-05 AIR-CORE COIL
L16,17 L40-5675-92 SMALL FIXED INDUCTOR (56NH)
L201 L34-4530-05 COIL
L202,203 L40-1095-34 SMALL FIXED INDUCTOR (1UH)
L204 L40-1005-34 SMALL FIXED INDUCTOR (10UH)
L205 L34-4526-05 COIL
L206 L34-4527-05 COIL
L207 L34-4526-05 COIL
L208 L34-4527-05 COIL
L209 L34-4526-05 COIL
L210 L34-4527-05 COIL
L211 L40-1005-34 SMALL FIXED INDUCTOR (10UH)
L212 L40-3381-37 SMALL FIXED INDUCTOR (0.330UH)
L213 L40-1281-37 SMALL FIXED INDUCTOR (0.120UH)
L214 L40-3975-34 SMALL FIXED INDUCTOR (39NH)
L215 L40-1885-34 SMALL FIXED INDUCTOR (180NH)
L216,217 L40-3375-34 SMALL FIXED INDUCTOR (33NH)
L218 L39-1272-05 TOROIDAL COIL
L219 L40-6895-34 SMALL FIXED INDUCTOR (6.8UH)
L220 L40-3375-34 SMALL FIXED INDUCTOR (33NH)
L221,222 L39-1272-05 TOROIDAL COIL
L223 L40-1005-34 SMALL FIXED INDUCTOR (10UH)
L224 L40-8271-34 SMALL FIXED INDUCTOR (82NH)
L225 L40-1085-34 SMALL FIXED INDUCTOR (100NH)
L501 L92-0138-05 FERRITE CHIP
L503 L40-5695-34 SMALL FIXED INDUCTOR (5.6UH)
L504 ✽ L41-3398-08 SMALL FIXED INDUCTOR
L505 ✽ L41-2798-08 SMALL FIXED INDUCTOR
L506 L40-3975-92 SMALL FIXED INDUCTOR (39NH)
L507 ✽ L41-3398-08 SMALL FIXED INDUCTOR
L508 ✽ L41-2798-08 SMALL FIXED INDUCTOR
L509 L40-3975-92 SMALL FIXED INDUCTOR (39NH)
L510 ✽ L34-4610-05 AIR-CORE COIL
L511 L34-4612-05 AIR-CORE COIL
L512,513 L40-1015-34 SMALL FIXED INDUCTOR (100UH)
L514 ✽ L41-2798-08 SMALL FIXED INDUCTOR
L515 ✽ L41-3398-08 SMALL FIXED INDUCTOR
L516 ✽ L41-2798-08 SMALL FIXED INDUCTOR
L517 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L519 L40-8275-92 SMALL FIXED INDUCTOR (82NH)
L520 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L700,701 L92-0138-05 FERRITE CHIP
L703 L92-0138-05 FERRITE CHIP
L704-713 L92-0140-05 FERRITE CHIP
X201 L77-1762-05 CRYSTAL RESONATOR (44.395MHZ)
X501 ✽ L77-1902-05 VCXO (16.8MHZ/2.5PP)
X700 ✽ L77-1896-05 CRYSTAL RESONATOR (12.288MHZ)
XF201 L71-0512-05 MCF (44.85MHZ WIDE)
XF202 L71-0513-05 MCF (44.85MHZ NARR)
CP700-715 R90-0740-05 MULTIPLE RESISTOR
R1 RK73GB1J102J CHIP R 1.0K J 1/16W
R2 RK73GB1J180J CHIP R 18 J 1/16W
R4 RK73GB1J100J CHIP R 10 J 1/16W
R5 RK73GB1J472J CHIP R 4.7K J 1/16W
R6 RK73GB1J471J CHIP R 470 J 1/16W
R7 RK73GB1J470J CHIP R 47 J 1/16W
R9 RK73GB1J220J CHIP R 22 J 1/16W
R10 RK73GB1J222J CHIP R 2.2K J 1/16W
R11 RK73GB1J101J CHIP R 100 J 1/16W
R12 RK73FB2A100J CHIP R 10 J 1/10W
R13 RK73FB2A180J CHIP R 18 J 1/10W
R14 R92-1252-05 CHIP R 0 OHM J 1/16W
R15 RK73FB2A180J CHIP R 18 J 1/10W
R16 ✽ R92-3513-05 RESISTOR 0.003 1W
R17,18 RK73GB1J104J CHIP R 100K J 1/16W
R19,20 RK73GB1J563J CHIP R 56K J 1/16W
R21 RK73FB2A101J CHIP R 100 J 1/10W
R22 RK73GB1J154J CHIP R 150K J 1/16W
R23 RK73GB1J104J CHIP R 100K J 1/16W
R24 RK73GB1J103J CHIP R 10K J 1/16W
R26 R92-1252-05 CHIP R 0 OHM J 1/16W
R27 RK73GB1J474J CHIP R 470K J 1/16W
R28 RK73GB1J103J CHIP R 10K J 1/16W
R29 R92-1252-05 CHIP R 0 OHM J 1/16W
R31 RK73GB1J101J CHIP R 100 J 1/16W
R32,33 RK73GB1J104J CHIP R 100K J 1/16W
R34 RK73EB2B101J CHIP R 100 J 1/8W
R36 RK73GB1J334J CHIP R 330K J 1/16W
R37 RK73GB1J104J CHIP R 100K J 1/16W
R38,39 RK73GB1J103J CHIP R 10K J 1/16W
R40,41 R92-1252-05 CHIP R 0 OHM J 1/16W
R42,43 RK73GB1J104J CHIP R 100K J 1/16W
R44 R92-1214-05 CHIP R 120 J 1/2W
R45-47 RK73GB1J473J CHIP R 47K J 1/16W
R48,49 RK73GB1J271J CHIP R 270 J 1/16W
R50 RK73GB1J681J CHIP R 680 J 1/16W
R51,52 RK73GB1J102J CHIP R 1.0K J 1/16W
R53 RK73GB1J471J CHIP R 470 J 1/16W
R54,55 RK73FB2A271J CHIP R 270 J 1/10W
R56 R92-1252-05 CHIP R 0 OHM J 1/16W
R58 RK73GB1J104J CHIP R 100K J 1/16W
R59 R92-1061-05 JUMPER REST 0 OHM
R101 RK73GB1J474J CHIP R 470K J 1/16W
R102 RK73GB1J394J CHIP R 390K J 1/16W
R103 RK73GB1J471J CHIP R 470 J 1/16W
R104,105 RK73GB1J334J CHIP R 330K J 1/16W
R106 RK73GB1J472J CHIP R 4.7K J 1/16W
R107-109 RK73GB1J473J CHIP R 47K J 1/16W
R110,111 RK73GB1J472J CHIP R 4.7K J 1/16W
R112 RK73GB1J102J CHIP R 1.0K J 1/16W
R113 RK73GB1J104J CHIP R 100K J 1/16W
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TX-RX UNIT (X57-6570-10)
