TK-7150
23
PARTS LIST
✽ New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert. L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Europe
Y : AAFES (Europe) X : Australia M : Other Areas
1 1B ✽ A01-2185-12 CABINET
2 3A ✽ A62-1037-03 PANEL ASSY
4 1C ✽ B11-1297-04 NAME PLATE
5 1D ✽ B62-1619-00 INSTRUCTION MANUAL
6 3A ✽ B72-2075-04 MODEL NAME PLATE
8 2A E04-0167-05 RF COAXIAL PECEPTACLE (M)
9 1C ✽ E30-3478-05 DC CORD ASSY
- E37-0808-05 LEAD WIRE WITH CONNECTOR
11 3A ✽ E37-1002-15 LEAD WIRE WITH CONNECTOR
12 1A ✽ E37-1003-05 LEAD WIRE WITH CONNECTOR (6P/ACC)
13 3A ✽ E37-1004-05 LEAD WIRE WITH CONNECTOR (TXRX-CONT)
14 1B,2C ✽ E37-1031-05 LEAD WIRE WITH CONNECTOR (SHORT PLUG)
15 1A ✽ E37-1074-05 LEAD WIRE WITH CONNECTOR (DC)
- ✽ E37-1075-05 LEAD WIRE WITH CONNECTOR
18 2C F05-1537-05 FUSE (BLADE) (15A/32V)
19 2B F09-0445-05 CAP (D-SUB)
20 2C ✽ F29-0478-05 PROTECTIVE COVER
22 2B G02-0861-04 FLAT SPRING
23 2B ✽ G02-0894-04 EARTH SPRING
24 2B ✽ G02-0896-04 FLAT SPRING
25 2B ✽ G02-0900-04 EARTH SPRING
26 2B ✽ G02-1801-03 EARTH SPRING
27 2B ✽ G02-1802-04 EARTH SPRING
28 1B ✽ G53-1551-02 PACKING
29 2A ✽ G53-1552-03 PACKING
30 1A ✽ G53-1554-03 PACKING
31 3A ✽ G53-1555-04 PACKING
33 3D ✽ H52-1894-02 ITEM CARTON CASE
35 2C J19-1584-05 HOLDER
36 2B ✽ J21-8437-14 HARDWARE FIXTURE
37 1C ✽ J29-0697-03 BRACKET
38 2C J61-0307-05 BAND
40 3A ✽ K29-9221-03 KNOB
41 3A ✽ K29-9222-02 KEY TOP
A 1B ✽ N09-2409-05 HEXAGON HEAD SCREW
B 3A N10-2070-46 HEXAGON NUT
C 1A,2B,3B N67-3008-46 PAN HEAD SEMS SCREW W
D 3A N80-2606-46 PAN HEAD TAPTITE SCREW
E 2B,3B N87-2606-46 BRAZIER HEAD TAPTITE SCREW
F 1B ✽ N87-2620-46 BRAZIER HEAD TAPTITE SCREW
G 1B,2B ✽ N87-3008-45 BRAZIER HEAD TAPTITE SCREW
43 2C ✽ N99-2033-05 SCREW SET
45 3A ✽ T07-0738-05 SPEAKER
46 1C T91-0621-15 MICROPHONE
48 3A ✽ X54-3400-10 DISPLAY UNIT
101 3A ✽ B38-0875-05 LCD ASSY
D908-911 B30-2254-05 LED
D912 B30-2193-05 LED (RED)
D913,914 B30-2254-05 LED
D915 B30-2194-05 LED (GREEN)
C901 CC73GCH1H101J CHIP C 100PF J
C902 CK73GB1H102K CHIP C 1000PF K
C903 CK73GB1H103K CHIP C 0.010UF K
C904 CK73GB1H102K CHIP C 1000PF K
C905,906 CC73GCH1H101J CHIP C 100PF J
C907 CK73GB1H102K CHIP C 1000PF K
C909,910 CC73GCH1H101J CHIP C 100PF J
C911,912 C92-0628-05 CHIP-TAN 10UF 10WV
C914 CK73GB1H102K CHIP C 1000PF K
C915-917 CC73GCH1H101J CHIP C 100PF J
C918,919 CK73GB1H103K CHIP C 0.010UF K
C921 CK73GB1H103K CHIP C 0.010UF K
C922 CC73GCH1H060B CHIP C 6.0PF B
C923 CK73GB1C223K CHIP C 0.022UF K
C924 C92-0628-05 CHIP-TAN 10UF 10WV
C925 CK73GB1H102K CHIP C 1000PF K
C926,927 CC73GCH1H270J CHIP C 27PF J
C928 CK73GB1H103K CHIP C 0.010UF K
C929,930 CK73GB1H102K CHIP C 1000PF K
C931 CK73GB1H103K CHIP C 0.010UF K
C932 CK73GB1H102K CHIP C 1000PF K
C933 CK73GB1H103K CHIP C 0.010UF K
C934,935 CK73GB1H102K CHIP C 1000PF K
C938,939 CK73GB1H102K CHIP C 1000PF K
C941,942 CK73GB1H102K CHIP C 1000PF K
C943 CK73GB1H103K CHIP C 0.010UF K
C944 CK73GB1H102K CHIP C 1000PF K
CN901 E40-5538-05 PIN ASSY
CN902 E40-6140-05 PIN ASSY
CN905 E40-5823-05 FLAT CABLE CONNECTOR
CN906 E40-5752-05 PIN ASSY
J901 E08-0877-05 MODULAR JACK
W1 3A ✽ E37-1057-05 LEAD WIRE WITH CONNECTOR
L901,902 L40-1095-34 SMALL FIXED INDUCTOR (1UH)
X901 L77-1863-05 CRYSTAL RESONATOR (12.0MHZ)
R902 RK73GB1J104J CHIP R 100K J 1/16W
R904,905 R92-1252-05 CHIP R 0 OHM J 1/16W
R906,907 RK73GB1J102J CHIP R 1.0K J 1/16W
R908 RK73GB1J473J CHIP R 47K J 1/16W
R909 RK73GB1J472J CHIP R 4.7K J 1/16W
R910 RK73GB1J104J CHIP R 100K J 1/16W
R913 RK73GB1J473J CHIP R 47K J 1/16W
R914 RK73GB1J561J CHIP R 560 J 1/16W
R915 R92-0670-05 CHIP R 0 OHM
R916-918 RK73GB1J473J CHIP R 47K J 1/16W
R919 RK73GB1J333J CHIP R 33K J 1/16W
R920 RK73FB2A560J CHIP R 56 J 1/10W
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
Ref. No. Address Parts No. Description
Desti-
nation
New
parts
TK-7150 DISPLAY UNIT (X54-3400-10)
TK-7150 (Y51-4910-10)
DISPLAY UNIT (X54-3400-10)
