Page 22
TK-7150
22
PARTS LIST
Chip capacitor
Code
L
W
T
Empty
5.6±0.5
5.0±0.5
Less than 2.0
A
4.5±0.5
3.2±0.4
Less than 2.0
B
4.5±0.5
2.0±0.3
Less than 2.0
C
4.5±0.5
1.25±0.2
Less than 1.25
D
3.2±0.4
2.5±0.3
Less than 1.5
E
3.2±0.2
1.6±0.2
Less than 1.25
F
2.0±0.3
1.25±0.2
Less than 1.25
G
1.6±0.2
0.8±0.2
Less than 1.0
H
1.0±0.05
0.5±0.05
0.5±0.05
Chip resistor
Code
L
W
T
E
3.2±0.2
1.6±0.2
1.0
F
2.0±0.3
1.25±0.2
1.0
G
1.6±0.2
0.8±0.2
0.5±0.1
H
1.0±0.05
0.5±0.05
0.35±0.05
• Rating wattage
Code
Wattage
Code
Wattage
Code
Wattage
1J
1/16W
2C
1/6W
3A
1W
2A
1/10W
2E
1/4W
3D
2W
2B
1/8W
2H
1/2W
(Less than 10pF)
Code
B
C
D
F
G
(pF)
±0.1 ±0.25 ±0.5
±1
±2
CAPACITORS
C C
4 5
T H
1 H
2 2 0
J
1
2
3
4
5
6
1 = Type ... ceramic, electrolytic, etc.
4 = Voltage rating
2 = Shape ... round, square, etc.
5 = Value
3 = Temp. coefficient
6 = Tolerance
• Temperature coefficient
1st Word
C
L
P
R
S
T
U
Color*
Black
Red
Orange Yellow Green
Blue
Violet
ppm/°C
0
–80
–150
–220
–330
–470
–750
• Tolerance (More than 10pF)
Code
C
D
G
J
K
M
X
Z
P
No code
(%)
±0.25 ±0.5
±2
±5
±10
±20
+40
+80 +100 More than 10µF : –10~+50
–20
–20
–0
Less than 4.7µF : –10~+75
• Voltage rating
2nd word
A
B
C
D
E
F
G
H
J
K
V
1st word
0
1.0
1.25
1.6
2.0
2.5
3.15
4.0
5.0
6.3
8.0
–
1
10
12.5
16
20
25
31.5
40
50
63
80
35
2
100
125
160
200
250
315
400
500
630
800
–
3
1000 1250 1600 2000 2500 2150 4000 5000 6300 8000
–
CHIP CAPACITORS
(EX)
C C
7 3
F
S L
1 H
0 0 0
J
Refer to the table above.
1
2
3
4
5
6
7
1 = Type
(Chip) (CH, RH, UJ, SL)
2 = Shape
3 = Dimension
(EX)
C K
7 3
F
F
1 H
0 0 0
Z
4 = Temp. coefficient
1
2
3
4
5
6
7
5 = Voltage rating
(Chip) (B, F)
6 = Value
7 = Tolerance
RESISTORS
• Chip resistor (Carbon)
(EX)
R D
7 3
E
B
2 B
0 0 0
J
1
2
3
4
5
6
7
(Chip) (B, F)
• Carbon resistor (Normal type)
(EX)
R D
1 4
B
B
2 C
0 0 0
J
1
2
3
4
5
6
7
(Chip) (B, F)
1 = Type ... ceramic, electrolytic, etc.
5 = Voltage rating
2 = Shape ... round, square, etc.
6 = Value
3 = Dimension
7 = Tolerance
4 = Temp. coefficient
CC45
Color*
2nd Word
G
H
J
K
L
ppm/°C
±30
±60
±120
±250
±500
Example : CC45TH = –470±60ppm/°C
• Capacitor value
010 = 1pF
2
2
0 = 22pF
100 = 10pF
101 = 100pF
Multiplier
102 = 1000pF = 0.001µF
2nd number
103 = 0.01µF
1st number
L
W
T
• Dimension
