4.2. Cleaning
4-7
Cleaning the Grid
1. Take the grid cleaner from protective bag in the new
toner kit, and remove the cap.
☛
The grid cleaner pad is impregnated with water.
Perform the following cleaning procedure before
the pad dries.
2. Attach the grid cleaner to the printer with the pad
uppermost, as shown in the diagram.
3. After attaching the grid cleaner, repeat the action
of slowly pulling out and then pushing back in the
main charger unit at least 5 times. It is easier to
pull out the main charger for the first time if it is
raised slightly, as shown in the figure.
The grid part underneath the main charger is
cleaned by this procedure.
4. When the grid is clean, remove the grid cleaner
from the printer and dispose of it. The grid
cleaner is not re-usable.
5. After cleaning the charger wire, push the clean-
ing knob all the way in and close the side cover.
Protective Bag
Cap
Grid Cleaner
Grid Cleaner
Main Charger Unit
(1)
(2)
(3)
