1.3. Names of Parts
1-5
1.3.
Names of Parts
This section takes you on a guided tour of the printer, pointing out its major parts. The part names intro-
duced here will be used throughout this manual.
Front View
Face-down
Output Tray
Paper Stopper
Control Panel
MP
(Multi-Purpose)
Tray
Paper Feed Unit
Release Lever
Paper Cassette
Side Cover
Power Switch
Memory Card Slot
Transfer Roller
Paper Feed Unit
Registration Roller
Paper Size Window
