MAINTENANCE WORK ON CHASSIS AND ENGINE
181
700327-11
– Remove screw  with washer on the left and right side of the vehicle.
– Press the rear end up until the drill holes of the frame are level with the lower rear
drill holes of the frame rear.
– Fit the screw and washer on the left and right sides of the vehicle, and tighten.
Guideline
Screw, subframe M8 25 Nm
(18.4 lbf ft) Loctite ® 243™
700330-01
– Tighten the screw  on the left and right sides of the vehicle.
Guideline
Screw, subframe M8 25 Nm
(18.4 lbf ft) Loctite ® 243™
