MAINTENANCE WORK ON CHASSIS AND ENGINE
117
700343-01
– Remove screws  and take off the shift rod.
– The length of the shift rod can be adjusted by means of the screw thread.
Guideline
Shift rod 115… 130 mm (4.53… 5.12 in)
– Loosen the counter nuts
 .
– Adjust the shift shaft.
Info
Make the same adjustments on both sides.
After the counter nuts have been tightened, the bearings of the shift shaft must
be central and aligned identically to each other in order to ensure freedom of
movement in the bearing shells.
At least 5 screw threads must be screwed into the seating.
– Tighten the counter nuts.
