KTM 1190 RC8 FR - Manual (Page 180)

MAINTENANCE WORK ON CHASSIS AND ENGINE
178
9.74
Adjusting handlebar height
Info
The handlebar stub position must be identical on the left and the right of the vehicle.
700318-01
– Loosen screw  .
Info
Loosen the screw several turns to prevent damaging the fork lacquer when mov-
ing the handlebar stub.
– Remove screw  .
700319-01
– Remove the spacer  .
– All cables routed under the upper triple clamp must now be routed under the handlebar
stub.
– Push the handlebar stub carefully up to the upper triple clamp.
– Mount and tighten screw.
Guideline
Remaining chassis screws M5 5 Nm (3.7 lbf ft)
