MAINTENANCE WORK ON CHASSIS AND ENGINE
139
700311-01
– Remove nut  . Remove chain adjuster  . Withdraw the wheel spindle  .
700312-01
– Push the rear wheel forwards as far as possible and take the chain off the rear sprocket.
– Pull the rear whell backwards until the brake caliper support
 hangs free between the
brake disc and the wheel rim.
Warning
Danger of accidents Reduced braking effect caused by damaged brake discs.
– Always lay the wheel down in such a way that the brake discs are not dam-
aged.
– Take the rear wheel carefully out of the swingarm without damaging the rim and/or
brake disc.
Info
Do not operate the foot brake when the rear wheel is removed.
