15
First Installation
Note: If you are unsure whether you chose the right option from a previous
menu, you can go back a step at any time during the first installation
process by pressing the
 button.
Press the  buttons here to select the connection mode and signal
configuration for the second tuner set on the receiver by you or the
engineer.
You have the following options:
Connection mode for tuner 2
- Separated: Tuner 2 (input) has its own signal input, i.e. a direct
connection between the antenna socket and the tuner 2 input
- Loop-through: The signal currently connected to the tuner 1 loop-
through output is looped-through to tuner 2 (input). Refer also to the
section headed “Operation on one Antenna Connection”
Signal configuration for tuner 2 (only in “Separated” connection
mode)
- Same with tuner 1: Both tuners are connected to the same signal
source (same cable from LNB)
- Different to tuner 1: The two tuners are connected to different signal
sources (separate cables from LNB)
Press

to move to the next menu. The notes on the subsequent First
Installation menus are divided into two columns. The left-hand column
indicates the further installation procedure for the “Same with tuner 1”,
signal configuration, while the right-hand column details the “Different
to tuner 1” procedure.
The satellites shown in the following screenshots are factory
preset. To be able to receive the satellites you want, your system
must be aligned to them!
