11
Note:
This will only work when receiving one satellite, not in multifeed
reception!
If only tuner 1 is connected (with no connection to tuner 2), the “Single
Mode” setting must be selected for the tuner input. You can then have
only the possibilities offered by a normal “single” receiver available to
you.
If this setting is not made, malfunctions will occur and the following
message will be displayed:
No signal!
Connection and Setup
TV and Video Recorder Connection
Connect the satellite receiver (TV Scart socket) and the TV set by a
Scart cable (see “Connection example”).
If your TV has a stereo feature, you can receive the sound in stereo via
the Scart connection.
Connect the satellite receiver (VCR/AUX Scart socket) and the video
recorder/PVR likewise by a Scart cable.
For system reasons, the same video signals are to be found on the
Scart outputs and on the video cinch output.
If you are recording using an external video recorder, remember not
to operate the receiver during recording, otherwise all the on-screen
displays will appear on your recording.
Audio Connection
If you want to play the sound on your hi-fi system, connect the audio
cinch sockets to the input sockets on the hi-fi system with an appropriate
cable (see “Connection Example”).
Optical Digital Output
The fibre-optic output is intended for the connection of a Dolby Digital
system (see “Connection Example”).
Inserting Batteries in the Remote Control
Remove the cover on the rear of the remote control.
Insert the two supplied batteries into the remote control. Ensure correct
polarity of the batteries; the + and – markings are indicated inside the
battery compartment.
Slide the cover back into the housing until it locks in place.
Used batteries are special waste!
Do not throw spent batteries into your domestic waste; take them to a
collection point for old batteries!
Electronic equipment is not domestic waste - in accordance with
directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND THE
COUNCIL dated 27 th January 2003 on used electrical and electronic
equipment, it must be disposed of properly.
At the end of its service life, take this unit for disposal at a relevant
official collection point.
Though a restriction on this is that with tuner 2 you can only receive the
additional channels of the plane currently set by tuner 1 (e.g. Horizontal
High).
