EXAMPLE 18–3 HTTP Service Schematic (Cluster and Enterprise Profile Version)
http-service *
|---connection-queue *
|---dns *
|---file-cache *
|---keep-alive *
|---virtual-server-1*
| |--- request *
|---virtual-server-2*
| |--- request *
The Resources Tree
The resources node holds monitorable attributes for pools such as the JDBC connection pool
and connector connection pool. The following schematic shows the top and child nodes for the
various resource components. The nodes at which monitoring statistics are available are
marked with an asterisk (*). See
“JDBC Connection Pools Statistics” on page 182 .
EXAMPLE 18–4 Resources Schematic
resources
|---connection-pool1(either connector-connection-pool or jdbc)*
|---connection-pool2(either connector-connection-pool or jdbc)*
The Connector Service Tree
The connector services node holds monitorable attributes for pools such as the connector
connection pool. The following schematic shows the top and child nodes for the various
connector service components. The nodes at which monitoring statistics are available are
marked with an asterisk (*). See
“JMS/Connector Service Statistics” on page 184 .
EXAMPLE 18–5 Connector Service Schematic
connector-service
|--- resource-adapter-1
| |-- connection-pools
| | |-- pool-1 (All pool stats for this pool)
| |-- work-management (All work mgmt stats for this RA)
The JMS Service Tree
The JMS services node holds monitorable attributes for pools such as the connector connection
pool. The following schematic shows the top and child nodes for the various JMS service
components. The nodes at which monitoring statistics are available are marked with an asterisk
(*).
About Monitoring
Sun GlassFish Enterprise Server 2.1 Administration Guide • December 2008 174
