W-3WAY ECO-i SYSTEM Unit Specifi cations
1
2
3
4
5
6
7
8
1. Outdoor Unit
1-1. Specifi cations
Unit Specifi cations (1)
MODEL NAME W-3WAY ECO-i Capacity Control Outdoor Unit <10 horsepower>
MODEL No. CHDZ09053
SOURCE 208-230V/3ø/60Hz
PERFORMANCE
Cooling capacity BTU / h (kW) 95,500 (28.0)
Heating capacity BTU / h (kW) 107,500 (31.5)
UNIT DIMENSIONS
Height in. (mm) 74-1/4 (1887)
Width in. (mm) 35 (890)
Depth in. (mm)
Ceiling dimension : 35 ~ +2-3/8
(890 ~ +60)
Net weight lbs. (kg) 657 (298)
Color (Munsell code) Silky shade (1Y 8.5 / 0.5)
ELECTRICAL RATINGS
Voltage rating V 208 230
Cooling
Running amperes A 25.0 22.6
Power input kW 8.12 8.12
Power factor % 90.0 90.1
Heating
Running amperes A 24.6 22.2
Power input kW 7.97 7.97
Power factor % 90.0 90.2
Starting amperes A 140 136
COMPRESSOR
Type - Q'ty Hermetic type x 2
Motor output kW 3 + 3.75
Refrigeration oil
Type FV68S (Ether oil)
Charge amount gal 1.29
Crankcase heater W 25 + 32
Capacity control % –
Refrigerant amount at shipment lbs. (kg) R410A - 25.9 (11.8)
Refrigerant control Electronic expansion valve
Defrost method Reverse-cycle defrost, outdoor unit cycle defrost
Heat exchanger Aluminum plate fi n / Copper tube
FAN DEVICE
Type - Q'ty Propeller fan x 1
Air circulation CFM 5,650
External static pressure in.WG 0
Motor output (No. of poles) kW 0.7/8P
Protective devices High pressure switch, overcurrent (CT method)
TUBING
Refrigerant tubing
Suction tube in. (mm) ш7/8 (ш22.22) (Brazing)
Discharge tube in. (mm) ш3/4 (ш19.05) (Brazing)
Liquid tube in. (mm) ш3/8 (ш9.52) (Brazing)
Balance tube in. (mm) ш3/8 (ш9.52) (Flare nut)
Drain port –
External air temperature operation range °F Cooling: 14 ~ 109 °F (DB) Heating: -4 ~ 59 (WB)
Operation sound (Hi) dB-A 55.0 (Quiet mode: 52.0)
Primary accessories
Connection tubing
ш7/8 (ш22.22), ш3/4 (ш19.05)
* Performance, electrical characteristics values and operating sound are based on JIS B8616 package A/C.
(Colling : Indoor intake air temperature 80°F DB / 67°F WB. Outdoor intake air temperature 95°F DB.)
(Heating : Indoor intake air temperature 70°F DB. Outdoor intake air temperature 47°F DB / 43°F WB.)
