HD-SDI Menu
40
Note
The SETUP item does not appear when an HD signal of
50i format is output.
HD-SDI Menu
The HD-SDI menu is displayed only when the HFBK-
HD1 HD Interface Board is inserted into the card slot of
the BRU-H700 HD Optical Multiplex Unit.
ANALOG OUT
Select the component signal output from the MONITOR
connector (D-sub 15-pin) on the HFBK-HD1 HD
Interface Board.
YPbPr: Outputs analog component signals.
RGB: Outputs RGB signals.
SYNC/VD
Select the signal output from the SYNC output on the
MONITOR connector
SYNC: Outputs the tri-level sync.
VD: Outputs the bi-level sync.
ADD SYNC
Appears when RGB is selected with ANALOG OUT
and specifies whether to add a sync signal.
RGB: Outputs each R, G and B signal with a sync signal
added.
OFF: Outputs each signal with no sync signal added.
>ANALOG OUT
SYNC/VD
YPbPr
SYNC
