Sony BRC-Z700 - Manual (Page 39)

Ad
jus
ting an
d
S
e
tti
ng Wit
h
Men
u
s
SD-SDI Menu / DOWN CONVERTER Menu
39
SD-SDI Menu
The SD-SDI menu is displayed only when the BRBK-
HSD1 HD/SD-SDI Output Card is inserted in the card
slot of the camera and the HD/SD select switch on the
Board is set to SD.
IMG SIZE
Select the aspect ratio of the output signal.
16:9 [LETTER]: The image is displayed in 16:9
letterbox.
4:3 [CROP]: The image is displayed in 4:3 edge crop.
4:3 [SQUEEZE]: The image is displayed in 4:3
squeeze.
DOWN CONVERTER
Menu
The DOWN CONVERTER menu is displayed only
when the HFBK-SD1 SD Interface Board is inserted in
the card slot of the BRU-H700 HD Optical Multiplex
Unit.
D-SUB OUT1
Select the component signal output from the MONITOR
connector (D-sub 9-pin) on the HFBK-SD1 SD
Interface Board.
YPbPr: Outputs analog component signals.
RGB: Outputs RGB signals.
ADD SYNC
Appears when RGB is selected with D-SUB OUT1 and
specifies whether to add a sync signal.
RGB: Outputs each R, G and B signal with a sync signal
added.
G: Outputs the G signal with a sync signal added.
OFF: Outputs each signal with no sync signal added.
D-SUB OUT2
Select the output signal from the MONITOR connector
on the HFBK-SD1 SD Interface Board.
VBS: Outputs analog composite signals.
Y/C: Outputs S-video signals.
IMG-SIZE (image size)
Select the aspect ratio of the output signal.
16:9[LETTER]: The image is displayed in 16:9
letterbox.
4:3[CROP]: The image is displayed in 4:3 edge crop.
4:3[SQUEEZE]: The image is displayed in 4:3
squeeze.
SETUP
Select whether 7.5IRE setup is added to output signals.
ON: Outputs signals with 7.5IRE setup added.
OFF: Outputs signals with no 7.5IRE setup added.
>IMG SIZE 16:9[LETTER]
>D-SUB OUT1
D-SUB OUT2
IMG SIZE
SETUP
YP b P r
VBS
16:9[LETTER]
OFF
