System Configuration
11
System Configuration
The BRC-Z700 HD 3CMOS Color Video Camera has various system configuration capabilities using optional
products. This section describes eight typical system examples with the required components and the main usage of each
system.
Operating a BRC-Z700 Camera Using the Supplied Remote Commander
This system allows you:
To operate the camera readily from a short distance
System configuration
Operating a BRC-Z700 Camera Using the RM-BR300 Remote Control Unit
This system allows you:
To perform pan/tilt and zoom operations using the joystick of the Remote Control Unit
System configuration
BRC-Z700
Video signal
Signal flow
Remote Commander
(supplied)
HD video monitor, VTR, etc.
,
HD video monitor, VTR, etc.
BRC-Z700
RM-BR300 Remote Control Unit
Video signal
Remote Control (VISCA) signal
Signal flow
