34
REPLACEMENT DECALS AND INFORMATION PLATES
1 2
3
6 5
4
7
9
12
13 14 15
10 11
8
48072
HEAVY DUTY
COMMERCIAL
ROTATING BLADES AND BELTS
WARNING
KEEP HANDS, FEET & CLOTHING CLEAR
KEEP ALL GUARDS IN PLACE
SHUT OFF ENGINE & DISENGAGE BLADE
CLUTCH BEFORE SERVICING
CLEAR AREA OF DEBRIS BEFORE MOWING
USE CAUTION IN DIRECTING DISCHARGE
KEEP BYSTANDERS, CHILDREN & PETS AWAY
READ INSTRUCTION MANUAL BEFORE OPERATING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED 481040
MANUFACTURED UNDER ONE OR MORE
OF THE FOLLOWING PATENTS:
PATENTS PENDING
4,487,006
4,885,903
4,920,733
4,967,543 4,991,382
4,998,948
4,118,617
DANGER
SPINNING BLADE
KEEP CLEAR
CONTACT CAN INJURE
48071
R
DANGER
ROTATING BLOWER
BLADES
STOP ENGINE BEFORE
ENTERING CHUTE
CONTACT CAN INJURE
481377
CAUTION
AVOID INJURY FROM
BURNS. SHUT OFF
ENGINE BEFORE
REMOVING FUEL
TANK CAP.
481272
CUTTING HEIGHT
ADJUSTMENT
1
1-1/2
2
2-1/2
3
3-1/2
4
CUTTING HEIGHT
INCHES
481493
CHOKE
SLOW FAST
R
481348
PARKING
BRAKE
OFF
ON
R
FAST
SLOW
SPEED
SELECTOR
CAUTION
KEEP BYSTANDERS AWAY
CAUTION
BEFORE OPERATING
READ OPERATINGS
MANUAL AND SAFETY
INSTRUCTIONS
START / DRIVE
PROCEDURE
ENGAGE PARKING BRAKE
DISENGAGE MOWER DECK DRIVE
MOVE SPEED SELECTOR HANDLE
TO NEUTRAL POSITION
START ENGINE
RELEASE PARKING BRAKE
SELECT SPEED WITH
SELECTOR HANDLE
SELECT FORWARD OR REVERSE
DIRECTION WITH HYDRO
CONTROL HANDLES
481349
NEUTRAL
N
DANGER
ROTATING BLOWER
BLADES
STOP ENGINE BEFORE
ENTERING CHUTE
CONTACT CAN INJURE
481378
USE CAUTION IN
DIRECTING DISCHARGE
THROWN OBJECTS
CAUTION
PULL UP AND PUSH
FOR
W
ARD T
O
ENGA
GE
MO
WER DECK ON
ON
ST
AR
T
MO
WER DECK OFF PULL B
A
CK
T
O
DISENGA
GE
OFF
481239
48404
390S0074
DUMP
VALVE
FREE
WHEEL
481350
DRIVE
