13
Ref. Part.
No. Number Description
- 481225 Pump, L.H. (Includes items 1 thru 30)
- 481226 Pump, R.H. (Includes items 1 thru 30)
1 HG2513038 Pump Shaft Kit
2 HG2003016 Wire Retaining Ring
3 HG2003043 Ball Bearing
4 HG2003018 Spacer
5 HG9008000-0128 Lip Seal (16 x 35 x 7)
6 HG2003052 Retaining Ring
7 HG2003023 Cradle Bearing
8 HG9008000-0126 Lip Seal (12 x 35 x 7)
9 HG2003005 Trunnion Arm
10 HG2000015 Slot Guide
11 HG2513020 Transmission Housing Kit (L.H.)
11 HG2513003 Transmission Housing Kit (R.H.)
12 HG2003044 Thrust Ball Bearing Assembly
13 HG9008000-0127 Lip Seal (15 x 24 x 7)
14 HG2003032 Motor Shaft
15 HG2003017 Block Thrust Washer
Ref. Part.
No. Number
Description
16 HG2003087 Variable Swash Plate
17 HG70079 BDT-10L Block Assembly
18 HG9004800-2506 Pin ST Holder
19 HG2513006 Center Section Kit
20 HG2510027 Check Valve Kit
21 HG2510011 Charge Relief Kit
22 HG9007314-0808 Socket Head Capscrew
23 HG2513011 Bypass Valve Kit
24 HG9004101-1340 O-Ring
25 HG2513027 Charge Pump Cover
26 HG50273 Gerotor Assembly
27 HG50095 Capscrew (6mm x 20)
28 HG2003060 Center Section Gasket
29 HG2513013 Overhaul Seal Kit
30 HG2000025 Spring Block
HYDRAULIC PUMP
