23
1 481245 Knob
2 04020-04 Hex Nut, 3/8-16
3 45753 Lever, Speed Control
4 481243 Disc, Friction
5 422197 Mounting, Plate, Speed Selector
6 04001-122 Bolt, Hex Head, 5/8-11 x 2-1/4"
7 04001-53 Bolt, Hex head, 5/16-18 x 2-1/2"
8 04030-03 Lockwasher, 5/16"
9 43380 Spacer, Speed Control
10 421880 Mounting Plate, Speed Control
11 04001-08 Bolt, Hex Head, 5/16-18 x 3/4"
12 04040-15 Flatwasher, 5/16 (.375 x .875 x .083)
13 48796 Bushing, Self-Aligning
14 04021-10 Hex Locknut, Elastic Stop, 5/16-18
15 421879 Mounting Plate, Left Bearing
16 04050-01 Ring, Retaining, .625"
17 481509 Bushing, Oilite, .627" ID
18 46889 Lever, L.H. Speed Control
19 48114-04 Grease Fitting
20 48051 Spring
21 04001-32 Bolt, Hex Head, 3/8-16 x 1-1/4"
22 04019-04 Serr. Fl. Hex Nut, 3/8-16
23 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
24 04001-45 Bolt, Hex Head, 3/8-16 x 2.0"
25 04015-10 Capscrew, Socket Head, 1/4-20 x 1/2"
26 04021-08 Hex Locknut, Elastic Stop, 1/4-20
27 04060-06 Roll Pin
28 04001-59 Bolt, Hex Head, 1/4-20 x 1-1/4"
29 04030-02 Lockwasher, 1/4"
30 04040-03 Flatwasher, 1/4 (.281 x .625 x .065)
31 48829 Block, Pump Control
32 421203 Clamp Plate, Pump Control
33 422273 Plate, Coupler
34 04017-05 Serr. Fl. Hex Head CPSCRW, 1/4-20 x 3/4"
35 04017-18 Serr. Fl. Hex Head CPSCRW, 5/16-18 x 1-1/4"
36 45750 Arm, R.H. Pump Control
37 43376 Stop, Pump Arm
38 04021-05 Hex Locknut, 3/8-16
39 04021-09 Hex Locknut, Elastic Stop, 3/8-16
40 48464 Ball Joint, 3/8-24 R.H. Thread
41 04020-14 Hex Nut, 3/8-24 R.H. Thread
42 48590 Link
43 04020-17 Hex Nut, 3/8-24 L.H. Thread
Ref. Part.
No. Number
Description
44 48544 Rod End, 3/8-24 L.H. Thread
45 43212 Sleeve
46 04001-20 Bolt, Hex Head, 3/8-16 1-1/2"
47 04063-12 Key, 3/16 x 5/8 Woodruff
48 43371 Shaft Speed Control
49 04001-11 Bolt, Hex Head, 5/16-18 x 1-1/2"
50 481189 Rod End, 5/16-24 R.H. Thread
51 43161 Spacer
52 04020-13 Hex Nut, 5/16-24 R.H. Thread
53 43377 Link, Adjust-LH
54 04020-23 Hex Nut, 5/16-24 L.H. Thread
55 481188 Rod End, 5/16-24 L.H. Thread
56 46886 Control Lever
57 48114-08 Grease Fitting, 90°
58 04001-32 Bolt, Hex Head 3/8-16 x 1 1/4"
59 481242 Spring, Handle Return
60 422438 Handle, Control
61 48100-05 Bushing, Oilite, .753 ID
62 48114-05 Grease Fitting
63 461003 Lever, L.H. Control
64 461004 Lever, R.H. Control
65 43378 Link, R.H. Adjustment
66 481477 Grip, Hand Control
67 45745 Lever, Speed Control
68 04012-02 Setscrew, Socket Head, 1/4-20 x1/4"
69 43379 Link, Speed Control
70 43246 Link
71 04001-21 Bolt, Hex Head, 3/8-16 x 1-3/4"
72 422198 Plate, Speed Selector
73 04021-13 Hex Locknut, Elastic Stop 5/8-11
74 46890 Lever, R.H. Speed Control
75 43063 Spacer
76 45749 Arm, L.H. Pump Control
77 04032-04 Washer, Belleville, 5/8"
78 04019-03 Serr. Fl. Hex Nut, 5/16-18
79 48030-13 Clamp, .75 Dia
80 04001-19 Hex Head Bolt, 3/8-16 x 1.0"
Ref. Part.
No. Number Description
SPEED AND STEERING CONTROLS
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
