Hopper – Scag Power Equipment STR User Manual
Page 77
31
Ref. Part.
No.
Number Description
39
481451
Strap, Hopper Stop
40
04019-04
Serr. Fl. Hex Nut, 3/8-16
41
422241
Insulation, Hopper - Rear
42
04040-15
Flatwasher, 5/16 (.375 x .875 x .083)
43
04021-10
Locknut, 5/16-18 Elastic Stop
44
422058
Insulation, Hopper - R.H.
45
422228
Mount, Transition Chute - Side
46
422037
Mount, Transition Chute - Rear
47
481279
Chute, Transition
48
45779
Anchor, Spring
49
422052
Bar, Clamp
50
481424
Hopper
51
422180
Plate
52
44122
U-Bolt, 3/8-16
53
45839
Guide, Screen - Upper L.H.
54
481056
Spring, Switch
55
04010-01
Screw, Round Head, #10-32 x 1/2"
56
04031-01
Lockwasher, External Tooth, #10
57
04020-01
Hex Nut, #10
58
45796
Screen Stop
59
481353-01
Trim Seal
60
45840
Guide, Screen - Upper R.H.
61
45797
Screen
62
04017-16
Bolt, Hex Head 5/16-18 x 3/4"
63
481092-01
Wingnut, Plastic
64
45865
Frame, Hopper
65
481495
Spring, Switch Lever
66
04001-76
Hex Head Bolt, 5/16-18 x 4.0"
67
46864
Door Assy, Hopper
68
481519
Spring, Torsion
Ref. Part.
No. Number Description
1
45762
Frame, Hopper Door
2
481284
Bumper, Rubber
3
04019-03
Serr. Fl. Hex Nut, 5/16-18
4
422050
Retainer, Screen
5
422320
Guard, Latch
6
04017-06
Serr. Fl. Hex Head CPSCR, 1/4-20 x 1.00"
7
461010
Latch, Hopper Door
8
04041-22
Flatwasher, 1/4 (.258 x .500 x .0598)
9
481252
Door, Hopper
10
481282
Handle
11
04090-02
Pop Rivet, 3/16 x .652"
12
04021-08
Hex Locknut, Elastic Stop, 1/4-20
13
04040-14
Flatwasher, 1/4 (..312 x .75 x .065)
14
04041-19
Flatwasher, 3/16 (.196 x .469 x .048)
15
04091-01
Rivet, Lok Bolt, 1/4 x .85"
16
04019-02
Serr. Fl. Hex Nut, 1/4-20
17
04003-06
Carriage Bolt, 1/4-20 x 1.00
18
04001-20
Bolt, Hex Head, 3/8-16 x 1-1/2
19
04041-07
Flatwasher, 3/8 (.391 x .938 x .105)
20
43212
Sleeve
21
04003-09
Carriage Bolt, 1/4-20 x 1-1/4"
22
421960
Boss, Centering
23
421964
Support, Door - Inside
24
422179
Support, Hopper - Top
25
04021-09
Hex Locknut, Elastic Stop, 3/8-16
26
421977
Support, Hinge (L.H. Shown)
26
421978
Support, HInge (R.H. Not Shown)
27
481343
Spring, Hopper Door
28
04003-02
Carriage Bolt, 1/4-20 x 3/4"
29
04001-59
Bolt, Hex Head, 1/4-20 x 1.25"
30
43260
Bushing
31
04001-08
Bolt, Hex Head, 5/16-18 x 3/4"
32
421973
Shield, Hopper
33
04021-10
Hex Locknut, Elastic Stop, 5/16-18
34
421961
Tab, Centering
35
43308
Spacer
36
422278
Lever, Hopper Switch
37
48030-09
Clamp, Cable - .50"
38
04001-46
Bolt, Hex Head, 3/8-16 x 2-1/4"
HOPPER
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
