29
Ref. Part.
No. Number Description
1 481422 Harness, Engine
2 48023 Hourmeter
3 48298 Fuse, 20 Amp
4 48017-02 Key & Ring Assembly
5 48017-04 Nut, Hex, 5/8-32
6 48017-03 Lockwasher, 5/8 Internal
7 46883 Instrument Panel, Top With Decal
8 48798 Keyswitch
9 48787 Switch, Mower Engagement Electric Clutch
10 48788 Relay
11 04031-01 Lockwasher, #10 External Tooth
12 04021-01 Hex Locknut, Elastic Stop, #10-32
13 48022 Ammeter
14 45798 Base, Instrument Panel
15 04030-02 Lockwasher, 1/4"
16 04001-01 Bolt, Hex Head, 1/4-20 x 3/4"
17 04110-01 U-Nut
18 481363 Throttle and Choke Controls
19 04010-01 Screw, Washer Round Head, #10-32 x 1/2"
20 48787-01 Nut, Hex, 1/2-27
ELECTRICAL SYSTEM
Ref. Part.
No. Number Description
21 48717 Switch, Interlock - Seat
22 481474 Switch, Interlock - (Neutral and Hopper)
23 04001-44 Bolt, Hex Head, 1/4-20 x 1/2"
24 48029-16 Cable, Battery - Red
25 04020-02 Nut, Hex, 1/4-20
26 48029-17 Cable, Battery - Black
27 48030-11 Clamp, Double Cable
28 48030-10 Clamp, Cable
29 04021-10 Hex Locknut, Elastic Stop, 5/16-18
30 04021-01 Hex Locknut, Elastic Stop, #10-32
31 42413 Bracket, Fuse Holder
32 04010-11 Screw, Round Head, #10-32 x 1-1/2"
33 04031-03 Lockwasher, External Tooth, 5/16
34 04002-12 Bolt, Hex Head, M8-1.25 x 20
35 481275 Relay and Harness (incl. item 40)
36 04030-02 Lockwasher, 1/4
37 04002-14 Bolt, Hex Head, M6-1.125 x 10
38 48033-04 Nylon Sleeve, 24"
39 481421 Wire Harnes, STR
40 48788 Relay
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
