27
Ref. Part.
No. Number Description
1 48894 Cap, Hydraulic Reservoir Fill
2 481240 Tank, Hydraulic Oil
3 48571-02 Cap, 3-4-16 JIC
4 48810-01 Tee, 3/4-16 JIC x O-Ring
5 481241 Hose Assembly, Filter Inlet
6 48603-04 O-Ring, 3/32 x 3/4 ID
7 48572-02 Union, Tube
8 481358 Hose Assembly, Case Drain
9 04017-04 Serr. Fl. Hex Head CPSCRW, 1/4-30 x 1/2"
10 48603-02 O-Ring, 3/32 x 5/8 ID
11 48350-02 Elbow, 90° JIC to O-Ring
12 48462-01 Element, Filter
12A 48462-02 Head, Filter
13 481359 Hose Assembly, L.H. Charge Pump
14 48350-10 Elbow, 90° 9/16-18 JIC to 7/16-20 O-Ring
15 48603-03 O-Ring, 1/16 x 3/8 ID
16 481384-01 Tee, 3/4-16 Swivel
17 481361 Hose Assembly, Case Drain Return
18 42945 Strap, Hydraulic Tank
19 04110-01 U-Nut
20 04010-10 Machine Screw, Round Head, 1/4-20 x 2.00"
21 48030-13 Clamp, Cable
22 04030-04 Lockwasher, 3/8"
23 04001-18 Bolt, Hex Head, 3/8-16 x 3/4"
24 481226 Pump, R.H.
25 481225 Pump, L.H.
26 481360 Hose Assembly, RH Charge Pump
27 481507 Insert, Filler Neck
28 48657 Rubber Pad
HYDRAULIC COMPONENTS AND LINES
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
