Sheet metal – Scag Power Equipment STR User Manual
Page 51
5
Ref. Part.
No. Number Description
1
48015
Battery
2
42392
Cover, Battery
3
04003-12
Carriage Bolt, 5/16-18 x 3/4
4
421197
Box, Battery
5
04029-01
Wingnut, Plastic, 1/4-20
6
04021-09
Hex Locknut, Elastic Stop, 3/8-16
7
04041-07
Flatwasher, 3/8 (.391 x .938 x .105)
8
04029-03
Wingnut, Plastic, 3/8-16"
9
422088
Belt Cover, Front
10
422089
Belt Cover, Rear
11
45950
Frame, Right Side
12
04019-04
Serr. Fl. Hex Nut, 3/8-16"
13
04019-03
Serr. Fl. Hex Nut, 5/16-18"
14
04017-39
Serr. Fl. Hex Head CPSCR, 1/2-13 x 2.00"
15
04017-37
Serr. Fl. Hex Head CPSCR, 1/2-13 x 1-1/4"
16
04001-32
Bolt, Hex Head, 3/8-16 x 1-1/4"
17
04003-14
Carriage Bolt, 5/16-18 x 1/2"
18
421894
Cross Brace, Frame
19
04001-20
Bolt, Hex Head, 3/8-16 x 1-1/2"
20
04110-01
U-Nut
21
422082
Heat Shield, Front
22
04017-18
Serr. Fl. Hex Head CPSCR, 5/16-18 x 1-1/4"
23
04019-06
Serr. Fl. Hex Nut, 1/2-13
24
04017-05
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4"
25
422311
Heat Shield, Side
26
421967
Link
27
45757
Frame, Bagger Support
28
481376
Spacer, Wheel
29
481249
Wheel, Bumper
30
04001-31
Bolt, Hex Head, 3/8-16 x 2-1/2"
31
422230
Heat Shield, Top
32
04003-11
Carriage Bolt, 3/8-16 x 1-1/4"
33
43419
Pivot, Seat Latch
34
04040-15
Flatwasher, 5/16 (.375 x .875 x .083)
35
04021-10
Hex Locknut, Elastic Stop, 5/16-18
36
04017-26
Serr. Fl. Hex Head CPSCR, 3/8-16 x 3/4"
37
04027-04
Castle Nut, 1.00"-14 UNS-2B
38
48668
Bearing With Race
39
48114-04
Grease Fitting
40
04001-12
Bolt, Hex Head, 5/16-18 x 1-3/4"
41
421902
Shield, Engine
42
04021-08
Hex Lock Nut, Elastic Stop, 1/4-20
43
04001-54
Bolt, Hex Head, 3/8-16 x 3.00"
44
45940
Yoke, Rear Caster
45
04021-13
Hex Locknut, Elastic Stop, 5/8-11
46
04001-40
Bolt, Hex Head, 5/8-11 x 9.00"
47
04001-19
Bolt, Hex Head, 3/8-16 x 1.00"
48
04030-04
Lockwasher, 3/8"
49
43020-07
Spacer
50
481303
Tire and Wheel Assembly (inlcudes 51 thru 56)
51
48005-06
Seal
52
48005-05
Cone, Bearing
SHEET METAL
Ref. Part.
No.
Number Description
53
48005-04
Cup, Bearing
54
48114-06
Grease Fitting
55
481303-03 Rim
56
481303-02 Tire
57
43405
Sleeve, Rear Tire
58
48100-06
Bushing, Oilite, .753 ID
59
46959
Shaft, Push Arm Mounting
60
43434
Pivot, Pusharm
61
04001-13
Bolt, Hex Head, 5/16-18 x 2-3/4"
62
04017-26
Serr. Fl. Hex Head CPSCR, 3/8-16x 3/4"
63
422085
Latch, Seat
64
48050
Spring
65
45949
Frame, Left Side
66
461013
Fender, Left With Decal
67
45824
Crossbrace
68
461026
Frame, Main
69
422455
Crossmember, Front
70
04017-16
Serr. Fl. Hex Head CPSCR, 5/16-18 x 3/4"
71
481389
Spring, Seat
72
04001-130 Bolt, Special
73
04003-02
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4"
74
422090
Actuator, Seat Switch
75
481246
Hinge, Seat
76
45800
Seat Base
77
04001-08
Bolt, Hex Head, 5/16-18 x 3/4"
78
04030-03
Lockwasher, 5/16"
79
481362
Seat
80
45875
Mounting Brkt. Wlmt., Deck Springs
81
421899
Brace, Bucket Support
82
481388
Hinge, Gearbox Cover
83
43404
Spacer
84
46885
Fender, Right With Decal
85
04003-12
Carriage Bolt, 5/16-18 x 3/4"
86
04003-01
Carriage Bolt, 1/4-20 x 6.00"
87
48661
Pad, Rubber
88
46966
Cover, Gearbox With Decal
89
422087
Bracket, Dump Valve
90
481374
Spring Cover
91
04001-09
Bolt, 5/16-18 x 1.00"
92
481250
Spring , Deck
93
422229
Cover, Access Hole
94
04001-01
Bolt, Hex Head 1/4-20 x 3/4"
95
422292
Prop Rod, Hopper
96
04003-05
Carr. Bolt, 3/8-16 x 1-1/2"
97
43260
Washer, Step
98
481501
Bushing, 1.003 ID x 2.10"
99
04021-14
Nut, 3/4-16 UNF Elastic Stop
100
04030-13
Flatwasher, 1/2 (.562 x 1.375 x .109)
101
04061-04
5/32 x1 1/2" Ext. Prg. Cotter Pin
102
481559
Cap, Grease
103
481025
Seal, 2.00" OD x 1.625" Bore
104
04110-02
U-Nut, 5/16-18
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
-NOTE-
