25
Ref. Part.
No. Number Description
1 45808 Lever, Dump Valve
2 04062-02 Hairpin
3 44116 Rod, Brake - L.H.
4 04020-22 Hex Nut, 1/4-28
5 48343-03 Clevis
6 04064-12 Pin, Clevis, 1/4 x 3/4"
7 04001-20 Bolt, Hex Head, 3/8-16 x 1-1/2"
8 04030-04 Lockwasher, 3/8"
9 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
10 45805 Actuator, Brake
11 04050-10 Ring, Retainer
12 45841 Mounting Bracket, Dump Valve
13 48840 Cable Assembly, Parking Brake
14 04019-03 Serr. Fl. Hex Nut, 5/16-18
15 04017-17 Serr. Fl. Hex Head CPSCR, 5/16-18 x 1.00"
16 04003-02 Carriage Bolt, 1/4-20 x 3/4"
PARKING BRAKE AND DUMP VALVE LINKAGES
Ref. Part.
No.
Number Description
17 422183 Bracket, Dump Valve Lever
18 04019-02 Serr. Fl. Hex Nut, 1/4-20
19 44117 Rod, Brake - R.H.
20 48950 Spring
21 45806 Lever, Parking Brake
22 48050 Spring, Control Detent
23 04001-46 Bolt, Hex Head, 3/8-16 x 2-1/4"
24 04021-09 Hex Locknut, Elastic Stop, 3/8-16
25 43063 Spacer
26 481365 Grip, Parking Brake Lever
27 422084 Latch, Brake Lever
28 04017-16 Serr. Fl. Hex Head CPSCRW, 5/16-18 x 3/4"
29 43032 Swivel Joint
30 04001-59 Bolt, Hex Head, 1/4-20 x 1-1/4"
31 04019-02 Serr. Fl. Hex Nut, 1/4-20
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
