3
Ref. Part.
No. Number Description
35 48006-07 Retainer, Caster Wheel
36 48006-06 Roller Bearing, Caster Wheel
37 48307-08 Tapered Hex Nut, 5/16-24
38 48307-04 Rim Pair, Caster Wheel
39 48006-05 Hub Assembly with Bolts
40 48114-03 Grease Fitting
41 48307-02 Tire
N/S 48006-03 Inner Tube
42 481311 Isolator, Rubber
43 04050-04 Retainer Ring, 1.00"
44 48100-01 Bushing, Oilite, .877 ID
45 422046 Spacer
46 421928 Mounting Bracket - Front
47 04001-10 Bolt, Hex Head, 5/16-18 1-1/4"
48 481596 Gearbox Assembly (Includes 48A ,48B And 48C)
48A 481626 Gearbox, LH
48B 481627 Gearbox, RH
48C 481410 Gearbox, Center
49 421929 Mounting Bracket - Rear
50 44121 Rod, Deck Prop - R.H.
51 481264 Bushing, Cutter Deck Support
52 04062-04 Hairpin, Cotter, .177 x 3.25"
53 04066-01 Quick Pin
54 04003-11 Carriage Bolt, 3/8-16 x 1-1/4"
55 422109 Bracket, Anti-Rotation
56 04031-08 Washer, Internal Lock
57 04001-143 Bolt, Hex Head, 7/16-20 x 1-3/4" LH Thread
58 43491 Spacer, Cutter Blade
59 * Capscrew, #10-32 x 3/4"
60 * Locknut, #10-32 Elastic Stop
61 04040-10 Flatwasher, 5/8" (.688 x 1.750 x .134)
62 04021-05 Locknut, 3/8-16
CUTTER DECK
Ref. Part.
No. Number
Description
1 45811 Foot Plate
2 04019-03 Serr. Fl. Hex Nut, 5/16-18
3 48114-04 Grease Fitting
4 46964 Frame, Cutter Deck Support (incl. 3,44,56)
5 04021-09 Hex Locknut, Elastic Stop, 3/8-16
6 44120 Rod, Deck Prop - L.H.
7 04017-16 Serr. Fl. Hex Head CPSCRW, 5/16-18 x 3/4"
8 04030-03 Lockwasher, 5/16"
9 04040-15 Flatwasher, 5/16 (.375 x .875 x .083)
10 45887 Guard, U-Joint
11 04021-10 Hex Locknut, Elastic Stop, 5/16"
12 04001-20 Bolt, Hex Head, 3/8-16 X 1-1/2"
13 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
14 04063-20 Key, 1/4 x 1/4 x 1.00"
15 481505 Drive Shaft
16 04001-09 Bolt, Hex Head, 5/16-18 x 1.00"
17 481262 Hinge, Discharge Chute
18 45767 Chute, Cutter Deck
19 04003-12 Carriage Bolt, 5/16-18 x 3/4"
20 46965 Cutter Deck With Decals
21 04003-23 Carriage Bolt, 3/8-16 x 1.0"
22 45863 Adapter, Blade Drive
23 481554 Blade, Cutter - L.H.
24 04041-18 Flatwasher, 7/16 (.469 x 1.50 x .25)
25 04030-05 Lockwasher, 7/16"
26 04001-102 Bolt, Hex Head, 7/16-20 x 1-3/4"
27 481555 Blade, Cutter - R.H.
28 04012-04 Setscrew, Hex Socket, 5/16-18 x 3/8"
29 49111 Caster Wheel Yoke Assy (Includes 30 thru34)
30 45768 Yoke, Caster Wheel
31 43022 Sleeve
32 04021-07 Hex Locknut, Elastic Stop, 1/2-13
33 04001-37 Bolt, Hex Head, 1/2-13 x 5-1/2"
34 48307 Caster Wheel Assembly (Includes 35 thru 41)
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
* Purchase part 461035 Shear Bolt Package to replace these parts. (4 of each per package)
