Chapter 6 Section 6.5
Implementing the HTTPS eWay BPEL Sample Projects Building and Deploying the prjHTTPClient_BPEL Sample Project
HTTPS eWay Adapter User’s Guide 66 Sun Microsystems, Inc.
To create a Business Process
1 Right-click the name of the sample Project, prjHTTPClient_BPEL, in the Project
Explorer
and choose New > Business Process from the pop-up menus. Rename the
Business Process to bpHTTPClient.
A blank Business Process canvas appears in the right pane, along with the Business
Process toolbar.
2 In the Project Explorer expand the icons for SeeBeyond > eWays for File and
HTTP
. Also expand the icon for the MultipleData_In_website OTD.
3 Arrange the Start and End icons at opposite sides of the canvas, then drag the
following icons onto the canvas:
From the Project Explorer:
Š HTTP eWay (server)
ΠOne get icon
ΠOne post icon
Š File eWay
ΠOne receive icon
ΠTwo write icons
Š MultipleData_In_website.unmarshal OTD icon
From the Business Process canvas toolbar:
Š Decision (a Decision End icon also appears)
Š Two Business Rule icons, for your two cases
4 Again by dragging, arrange these icons on the canvas as shown in Figure 21.
Table 11 Business Process Cases
Case Activity Result
Case 1: GET operation Requests that the Business Process
get information from the HTTP
server. Appropriate information is
retrieved.
Case 2: POST operation Requests that the Business Process
posts information to the HTTP
server. Appropriate information is
posted.
