Simrad ap50 autopilot 82, R f 14x u el ec t r on ic mod u le – Simrad AUTOPILOT SYSTEM AP50 User Manual
Page 84
Simrad AP50 Autopilot
82
20221032B
VI OLET
B R O W N
P I N K
BL
AC
K
RE
D
WH
IT
E
WH
IT
E
BL
AC
K
RE
D
BLUE ( GND)
Y EL L OW ( + 5V )
GR EEN ( WI PER)
N O T E 1
N O T E 2
9
8
1 0
7
6
5
R F 14X U EL EC T R ON IC MOD U LE
(V IE W E D FR OM B A CK S ID E )
NOTE 1: Brown lead normally connected to .
Move to to invert the rudder indicator deflection.
NOT E 2: Normally connec ted for +/-45˚ rudder angle (v iolet, brow n and pink leads are
not connected). For +/-60˚ connect brown lead to terminal 10, for +/-70˚ connect
pink lead to terminal 10, for +/-90˚ connect violet lead to terminal 10.
White lead must remain connected.
BR
O
W
N
8
9
8
9
T O
POT .
MET ER
Figure 4-9
RF14XU Internal wiring
Figure 4-10 shows how to connect the RF14XU Rudder
Feedback Unit to an AP50 system with 24V autopilot supply.
