Simrad AP50 Autopilot
118
20221032B
stored in the memory of the AP50 system. No specific action
is required to save the selected values to memory. Once the
value is changed, it is stored until the next time the menu
item is selected and changed.
• The Installation Set-up is considered global (except
language), which enables the values to be available to all
control units in the system.
• The values in the Seatrial Settings are dependent on the
successful completion of the Dockside Settings.
• In the table on page 159 the range of each setting is listed.
Note the final value selected during the Installation Set-up,
and also note any changes of values.
Before attempting to turn on the AP50 and perform an
Installation Set-up, the hardware installation and electrical
installation must be completed and performed in accordance
with the installation instructions.
5.2 Installation Menu
RUDDER
02
SETUP
REQUIRED
LANGUAGE
DOCKSIDE
INTERFACE
SEATRIAL
SERVICE
SETTINGS
SW V1R2
June 26 2003
No
Yes
A single press on the
STBY
(STBY) button switches the system on.
After approximately 5 seconds, the unit that was turned on will
show the Standby mode display. When the AP50 is delivered
new from the factory (and any time after a master reset of
memories has been performed), the Installation Set-up values are
all reset to preset (default) values. The warning message "Setup
Required" will appear at “turn on” and if an attempt to access the
AUTO or NAV modes is made.
The Installation Menu is presented on the autopilot display by
pressing and holding the
NAV
SETUP
(NAV/SETUP) button for 5
seconds.
Note ! The Installation Menu is different from the User Set-up Menu.
Refer to the flow diagram on page 120 for a pictorial view of the
Installation Menu.
Navigate through the Installation Menu as follows:
• Answer “Yes” to a question by rotating the course knob
clockwise.
• Answer “No” to a question by pressing the (STBD)
button. This will allow you proceed to the next menu item.
• Return to the previous menu item by pressing the (PORT)
button.
• Change the selected item shown rotating the course knob in
either direction.
