Advanced Settings
20221032B
159
SETTINGS
Displayed parameter Boat type (Default settings) Own boat
Dockside Menu Displacement Planing Waterjet Autotune Manual
Master Operation No No No
Boat length 0-50 feet 0-50 feet 0-50 feet
Drive unit voltage 12V 12V 12V
Rudder limit 10° 10° 10°
Rudder deadband AUTO AUTO AUTO
Thruster - - - - - - - - - - - -
Settings Menu
W Init rudder Actual Actual Actual
W Autotrim Yes Yes Yes
Autotrim 48 sec 40 sec 40 sec
Course adj. 1° 1° 1°
Compass diff. 10° 10° 10°
Off heading lim 10° 10° 10°
Drive engage Bypass/clutch
Drive type - - - - - - - - - - - -
Drive out 50% 50% 50%
Prop. gain 18 18 18
Seastate AUTO AUTO AUTO
Rudder 0.50 0.30 0.30
Counter rudder 0.90 0.90 0.90
W Seastate AUTO AUTO AUTO
W Rudder 0.75 0.45 0.45
W Count Rudder 1.40 1.40 1.40
W Rudder limit 10° 10° 10°
Cruising speed 15kt 15kt 15kt
Speed response 0.00 0.00 0.00
Transition speed OFF OFF OFF
Nav gain 3.5 3.5 3.5
Minimum rudder 0.0° 0.0° 0.0°
Turn mode ROT ROT ROT
Rate Of Turn 240°/min 240°/min 240°/min
W Rate Of Turn 240°/min 240°/min 240°/min
Added stop time 0s 0s 0s
Init NAV Firm Firm Firm
Turn gain 38 38 38
W Turn gain 38 38 38
Rate sensitivity 15 15 15
Thruster inhibit 10 kt 10 kt 10 kt
Thruster sens 1°/5° 1°/5° 1°/5°
Continuous 1.0 1.0 1.0 Thruster
gain
Adaptive on/ off 2.0 2.0 2.0
Minimum thrust 00 00 00
Thruster hyst 00 00 00
Thruster drive Continuous Continuous Continuous
Response delay 1.0 sec 1.0 sec 1.0 sec
