Technical Specifications
20221032B
67
3.22 FU50 Steering Lever
Dimensions:............................................................................................... See Figure 3-18
Handle can be mounted pointing upwards or downwards.
Weight: .............................................................................1.2 kg (2.6 lbs.) including cable
Material:..................................................................................................Polyacetal (POM)
Environmental Protection:........................................................................................... IP56
Power consumption: .....................................................................................................3W
Safe distance to compass: ........................................................................... 0.15 m (0.5 ft.)
Temperature:
Operating: ............................................................... –25 to +55°C (–13 to +130°F)
Storage: ................................................................... –30 to +80°C (–22 to +176°F)
Cable:....... 10 m (33 ft.) cable with three twisted pairs of wire run through a cable gland.
(cable gland can alternatively be mounted on back cover; see Figure 3-18)
Max. rudder command angle:...........................................Equal to physical stop minus 2°
Autopilot interface:............................................................. Via proprietary RobNet™ bus
Accuracy:............................................................±1° within ±40° of mid-position at 25°C
Figure 3-18 FU50 Steering Lever Dimensions
