Simrad AP50 Autopilot
104
20221032B
4.18 S35 NFU Steering Lever
The S35 NFU Steering Lever may be mounted to the bulkhead
or to a panel by two screws from the front. The cable is
connected to the junction unit according to Figure 4-31. If
necessary, interchange the Port and Stbd wires to the screw
terminals in the junction unit to make the direction of the lever
movement coincide with the direction of the rudder movement.
S35
STEERING LEVER
N O T E!
Dis r ega r d t h e co lor c ode
o n t h e t er mi na l lab el.
R E M O T E
JUNCTION UNIT
POWER PCB
TB1 TB2
TB3 TB5
Br
n
/W
h
Pnk
/G
ry
Gr
n
R EMOTE
TB4
Yel
St
bd
Po
rt Gn
d Lamp
Figure 4-31 S35 NFU Steering Lever Connection to Junction Unit
The steering lever is opened by removing the three screws on
the back cover. Inside are two sets of micro-switches, a printed
circuit board with a plug-in terminal, and a jumper strap.
4.19 F1/2 Remote Control
The F1/2 Remote Control comes with 10 m (33 ft.) of cable and
is connected to the junction unit as shown in Figure 4-32.
F1/2
REMOTE CONTROL
NO T E!
Dis r ega r d t h e co lor c ode
on t he t er mi nal lab el.
R E M O T E
JUNCTION UNIT
POWER PCB
TB1 TB2
TB3 TB5
Vi
o
le
t
Br
o
w
n
Be
ig
e
R EMOTE
TB4
St
bd
Po
rt Gn
d
Figure 4-32 F1/2 Remote Control Connection
