Chapter 1 Preparation
real time Capture function ( p.68)
To display the screen image of
the computer by the monitor
through the network in real
time.
Features
Network Viewer function ( p.81)
To acquire the JPEG image data
from the file servers placed in
the network and display them
by the monitor.
PC4 PC3 PC6
Capture
PC5
PC1 PC2
PC4 PC3 PC6
PC5
PC1 PC2
FTP file server
JPEG
Prog.
JPEG
MONITOR 2 MONITOR 1
Network Communication function ( p.71)
To communicate by sharing the
captured image of a computer
with multiple computers and
a monitor. User can draw the
text and figure on the captured
image by using a drawing tool.
PC2
PC6 Capture
PC5 PC1
MONITOR 1
Capture a screen
image of PC5 and
make marking with a
tool.
