10
Chapter 1 Preparation
Multi-control function ( p.59)
A single computer can con-
trol and set up the multiple
monitors at the same time.
PC6
PC4 PC5
Select Input2 for
MONITOR 1 to
MONITOR4.
MONITOR 1 MONITOR 2 MONITOR 3 MONITOR 4
automatic on/off using Clock function ( p.55)
Automatically turn on or off the
monitors at specified date/day
and time by using the clock func-
tion.
Now it’s 11:30
I am ready to turn ON,
and select Input 3 (Video)
sNMP Manager function (refer to the separated booklet)
A func tion to manage the
condition of monitors in the
network by using the SNMP
protocol. The managing com-
puter needs to provide an
SNMP managing software. Refer
to the owner's manual of the
"PJ Network Manager" supplied
separately for further details.
PC6
PC4 PC5
You received
a Trap.
SNMP Manager
Trap
Trap
MONITOR 3 MONITOR 1 MONITOR 2 MONITOR 4
sNMP agent function ( p.42)
To send the information of the
monitor to the SNMP manager.
Enables you to manage the
monitor condition with the sup-
plied SNMP manager software.
PC6
PC4 PC5
You received
a Trap.
SNMP Manager
Trap
Trap
MONITOR 3 MONITOR 1 MONITOR 2 MONITOR 4
