Characterization of Installation Site
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
JUNOSg 3.0 G10 CMTS Hardware Guide 80
Table 30: Downstream CMTS Parameter Characterization
Downstream Parameters Port 0 Port 1 Port 2 Port 3
DOCSIS Module #___
Node combining ratio per port ____ : 1 ____ : 1 ____ : 1 ____ : 1
Interface frequency allocated ____ MHz ____ MHz ____ MHz ____ MHz
Modulation type _ 64QAM _256QAM _ 64QAM _256QAM _ 64QAM _256QAM _ 64QAM _256QAM
Output signal level (relative to analog
video) ____ dB ____ dB ____ dB ____ dB
Required interface output level ____ dBmV ____ dBmV ____ dBmV ____ dBmV
Interleave depth setting ___ [I] (# of taps)
___ [J] (increments) ___ [I] (# of taps)
___ [J] (increments) ___ [I] (# of taps)
___ [J] (increments) ___ [I] (# of taps)
___ [J] (increments)
