Radio Frequency (RF) Specifications
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
JUNOSg 3.0 G10 CMTS Hardware Guide 178
Table 49: Downstream RF Signal Output Characteristics
Table 50: DOCSIS Downstream Channel Rates and Spacing
Parameter Value
Center Frequency (fc) 91 to 857 MHz ± 30 kHz 1
Level Adjustable over the range 50 to 61 dBmV
Symbol Rate (nominal)
64QAM
256QAM
5.056941 Msym/sec
5.360537 Msym/sec
Nominal Channel Spacing 6 MHz
Frequency response
64QAM
256QAM
~18% Square Root Raised Cosine shaping
~12% Square Root Raised Cosine shaping
Total Discrete Spurious Inband (fc ± 3 MHz)
Inband Spurious and Noise (fc ± 3 MHz)
Adjacent channel (fc ± 3.0 MHz) to (fc ± 3.75 MHz)
Adjacent channel (fc ± 3.75 MHz) to (fc ± 9 MHz)
Next adjacent channel (fc ± 9 MHz) to (fc ± 15 MHz)
Other channels (47 MHz to 1,000 MHz)
< -57dBc
< -48dBc; where channel spurious and noise includes all discrete spurious,
noise, carrier leakage, clock lines, synthesizer products, and other undesired
transmitter products. Noise within +/- 50kHz of the carrier is excluded.
< -58 dBc in 750 kHz
< -62 dBc, in 5.25 MHz, excluding up to 3 spurs, each of which must be
<-60 dBc when measured in a 10 kHz band
Less than the greater of -65 dBc or -12dBmV in 6MHz, excluding up to three
discrete spurs. The total power in the spurs must be < -60dBc when each is
measured with 10 kHz bandwidth.
< -12dBmV in each 6 MHz channel, excluding up to three discrete spurs. The
total power in the spurs must be < -60dBc when each is measured with
10kHz bandwidth.
Phase Noise 1 kHz - 10 kHz: -33dBc double sided noise power
10 kHz - 50 kHz: -51dBc double sided noise power
50 kHz - 3 MHz: -51dBc double sided noise power
Output Impedance 75 ohms
Output Return Loss > 14 dB within an output channel up to 750 MHz;
> 13 dB in an output channel above 750 MHz
Connector F connector per [IPS-SP-406]
1. ±30 kHz includes an allowance of 25 kHz for the largest FCC frequency offset normally built into upconverters.
Nominal Symbol Rate
(Msym/sec) Nominal Channel Spacing
(kHz)
Bit Rate (bps)
5.056941 (64QAM) 6000 30,341,646
5.360537 (256QAM) 6000 42,884,296
