Prepare the Site

G10 CMTS Installation Checklist

Install a Chassis Control Module and a Hard Disk Module

Remove the air management module where the Chassis Control Module will be inserted page 108

Release the ejectors, align to the card guides, insert the Chassis Control Module, and
close the ejectors

Tighten the self-contained screws

Remove the air management panel where the Hard Disk Module will be inserted

Release the ejectors, align to the card guides, insert the Hard Disk Module, and close the
ejectors

Tighten the self-contained screws

Install a NIC Module and a NIC Access Module

Remove the air management module where the NIC Module will be inserted

Release the ejectors, align to the card guides, insert the NIC Module, and close the
ejectors

Tighten the self-contained screws

Remove the air management panel where the NIC Access Module will be inserted

Release the ejectors, align to the card guides, insert the NIC Access Module, and close
the ejectors

Tighten the self-contained screws

Determine how the cable plant nodes will be connected to the downstream and
upstream ports of the module

Connect each of the four downstream ports to its respective node

Connect each of the four upstream ports to its respective node

Dress all cables appropriately

Thread the Ethernet cable through the cable channel from the rear of the chassis

Connect the RJ-45 connector of the Ethernet cable to the Eth0 port on the Chassis
Control Module

Connect the other end of the Ethernet cable to its respective network equipment in the
headend

Cable a NIC Module and a NIC Access Module (if applicable)

Thread the network cables through the cable channel from the rear of the chassis

Connect each of the two Gigabit Ethernet network cables to the ports on the NIC
Module

Connect the other ends of the network cables to their respective network equipment in
the headend

Connect the RJ-21 end of the NIC Access Module cable into the NIC Access Module and
tighten the cable retainer screws

Connect eight RJ-45 connectors of the NIC Access Module cable to a maximum of four
HFC Connector Module

Dress all cables appropriately

Connect the serial cable to the COM port on the Chassis Control Module

Connect the other end of the serial cable to the serial port on the PC

Step

Page Number

Completion Status
