Power On the G10 CMTS


























































JUNOSg 3.0 G10 CMTS Hardware Guide

126

Table 42: Chassis Control Module LED Status

8.

Immediately after the G10 CMTS is powered on, wait for the OK LED on the NIC Module
faceplate to illuminate green, which indicates the module initialization has been
successfully completed (see Figure 16 on page 43). Some LEDs will be in one state
during the initialization (OK LED not illuminated), then change to another state after the
initialization (OK LED illuminated green). Table 43 on page 126 indicates the expected
status of all LEDs on the module’s front panel. If the OK LED does not illuminate, the NIC
Module is considered faulty and you might have to replace it (see “Remove a NIC
Module” on page 170)
.

Table 43: NIC Module LED Status

9.

You should check the four LEDs at the top of the NIC Access Module rear panel after
confirming the LEDs on its corresponding NIC Module are in the correct state as

LED

Status

Meaning

Minor

Off

No event of priority Warning, Notice, Information, or Critical
has occurred.

Major

Off

No event of priority Error has occurred.

Critical

Off

No event of priority Emergency, Alert, or Critical has occurred.

Run

Green

Module is active.

ACO

Off

Alarm Cutoff not activated.

∆1 ∆2

Green On—Active

module.

Off—Stand-by module.

IDE

Off

IDE inactive.

Power

Green

Power is applied.

USR1

[TBD] [TBD]

USR2

[TBD] [TBD]

Hot Swap

Off

Not safe to remove module.

LED

Pre-initialization Status Post-initialization Status

Meaning

Pull

Red

Off

Normal operation.

0 through 23

Off

Off

No link or activity on
interfaces.

GB0 and GB1

Off

Off

No link on Gigabit
interfaces.

CLK

Green

Off

Undefined.

PWR

Green

Green

Power is applied.

RTM

Green

Green

Continuity established
with NAM.

OK

Off

Green

Successful initialization.

EXT FLT

Amber

Off

No external failure.

Amber

One or more of the FE or
GE ports is enabled, but
unused.

INT FLT

Amber

Off

No internal failure.

Hot Swap

Off

Off

Not safe to remove
module.
