Wheels, Tyres and Treads
GENERIC,0000058 –19–22FEB06–1/1
Adjust Front Axle Tread Width
PY5529
–UN–21FEB06
A—Tie Rod
B—Axle Nuts (4 used)
C—Cap Screws (4 used)
D—Sleeve (4 used)
E—Tie Rod Cap Screw
IMPORTANT: DO NOT place jack under engine oil
pan.
1. Jack up front end of tractor.
2. When making large tread adjustments, loosen cap
screws (E) and adjust the tie rod (A) length with axle
length.
3. Remove two nuts (B), sleeves (D), and cap screws (C)
from front axle (2 on each side).
4. Slide axle knees to desired position. Both sides should
be adjusted to same spacing.
5. Install sleeves (if equipped), cap screws and nuts on
each side. Tighten cap screws to specification.
Specification
Adjustable Front Axle-to-Knee
Bolts—Torque
400 N•m (295 lb-ft) ..............................................................
6. Set toe-in. See Check and Adjust Toe-In for your axle
type.
75-9
